Go big.

Another collaboration with the mighty Lil Shredder, a race ready enduro machine born of necessity on the black runs of Whistler. A bike fast enough, plush enough, and responsive enough to run back to back all summer long. This phenomenal machine is the peak of kids' performance bikes and the history of riders that have played a part of the bikes development is beyond comparison.

The HX24 uses a combination of 6061 and 6066 tubing to give the best possible stiffness to weight ratio. Frame components are fully CNC’d, single pivot suspension kinematics giving predictable and durable performance. Progressive geometry combines with the world's best aluminum frame maker, the HX24 is clean, simple and proven. It’s all hidden in the detail; stealth dropper post ready, ISCG tabs & a 4 bearing pivot.

Out of the box the bike comes setup in the 4 “ travel position, a fantastic and appropriate trail rig. But drop the rear shock mount into the 5” position, and see the headtube slacken by 1.5 degree, bb drop and turn the bike into a descending hooner!

A market leading 1 x11 Shimano clutch equipped drivetrain with a huge gear range. Rapid fire shifters for immediate transitioning, direct mounts cranks, narrow wide chainrings and external bottom bracket for super smooth drive transfer to an immensely capable wheel set. Tubeless ready, double walled rims, CNCd' straight pull hubs on thru axles and running high thread count folding tyres.

Supported by light actuating Shimano hydraulic brakes that provide immediate, powerful braking no matter the conditions and a proven 120mm travel RST fork specifically chosen to complement the geometry of the bike. The Hellion X24 is the bike that showed that kids can do everything that adults can do, if they have the right tools.

ASSEMBLY INSTRUCTIONS:

Your bike will arrive carefully packaged and boxed with the front and rear wheel detached. Attach both wheels using the skewers supplied and install the gearing mechanism. The handlebar will be ziptied to the top tube, simply remove the bars and all packaging and attach to the stem. Add the saddle and adjust to the required height. Then simply add the pedals. Please retain your manual.

[Left column]

INSIDE LEG

65CM

FRAME

BUTTED ALLOY FRAME, 100/125MM TRAVEL, DROPPER READY

REAR SHOCK

DNM AO-38RC, 165X38MM REBOUND ADJUST, PEDAL PLATFORM

FORK

RST FIRST AIR 15, 120MM TRAVEL, 15MM THRU AXLE, PM DISC MOUNT

CRANKS

SAMOX 150MM DIRECT MOUNT

PEDALS

SDG SLATER 90 PEDALS, BLACK

BOTTOM BRACKET

SAMOX 24MM EXTERNAL CUP, SEALED CARTRIDGE BEARING

RIMS

24 X 28H, DOUBLE WALLED AL6061, TUBELESS COMPATIBLE

REAR HUB

CNC'D STRAIGHT PULL AL6061, 12x142 (1.0) THRU AXLE

FRONT HUB

CNC’D STRAIGHT PULL AL6061, 15MM THRU AXLE

CHAIN

KMC X10

CHAINRING

SAMOX DIRECT MOUNT STEEL 30T

REAR CASSETTE

SHIMANO CS-M5100-11, DEORE, 11-SPEED 11-51T

SHIFTER

SHIMANO SL-M5100-IR, DEORE, RIGHT,11-SPEEDRAPIDFIRE

*Every effort has been made to ensure accuracy throughout this website. However, Early Rider reserves the right to change prices and bike specifications without prior notice*

CLICK TO VIEW THE USER MANUAL

[Right column]

WEIGHT

11.5KGS W/O PEDALS

AXLES

THRU AXLES AL7075, 15MM FRONT, 142 x 12MM REAR (1.0P)

DERAILLEUR

SHIMANO RD-M5100, DEORE,SGS 11-SPEED

BRAKES

SHIMANO DEORE BL-MT6000, 160MM ROTORS

LEVERS

SHIMANO DEORE BL-M6000

FRONT TYRE

VEE CROWN GEM SKINWALL 24*2.25" 72 TPI, FOLDING

REAR TYRE

VEE CROWN GEM SKINWALL 24*2.25" 72 TPI, FOLDING

HEADSET

SEMI INTEGRATED, TAPERED  1 1/8” - 1 1/5" CARTRIDGE BEARING

STEM

RITCHEY OS FORGED AL6061, 35MM REACH

BARS

640MM RITCHEY OS DOUBLE BUTTED AL6061, 18MM RISE

GRIPS

ER LOCK ON KRATON 115MM

SEAT POST

RITCHEY, 30.9MM x 350MM, AL6061

SADDLE

SDG FLY JR, BLACK

SEAT CLAMP

RITCHEY QR, 34.9MM
